Standard Cells, Hellma®

Table of material code


OGOptical glass (360 nm - 2500 nm)
OSOptical glass (320 nm - 2500 nm)
UVHOQ 310H (260 nm - 2500 nm)
QSQuartz SUPRASIL® (200 nm - 2500 nm)
QXQuartz SUPRASIL® 300 (200 nm - 3500 nm)



Absorption cells

Inside width 9.5 mm, base thickness 1.5 mm

Type/material

Vol.
µl		CoverOptical path length
mm		Outer dimensions H × W × D
mm		Order No.
100-OS 350glass lid 145×12.5×3.519 55 11011
100-OS 700glass lid 245×12.5×4.519 55 11021
100-OS 1750seamed lid 545×12.5×7.519 55 11051
100-OS 3500seamed lid 1045×12.5×12.519 55 11101
100-OS 7000seamed lid 2045×12.5×22.519 55 11201
100-OS14000seamed lid 4045×12.5×42.519 55 11401
100-OS17500seamed lid 5045×12.5×52.519 55 11501
100-OS35000seamed lid10045×12.5×102.519 55 11601
100-QS 350glass lid 145×12.5×3.519 55 11012
100-QS 700glass lid 245×12.5×4.519 55 11022
100-QS 1750seamed lid 545×12.5×7.519 55 11052
(1)100-QS 3500seamed lid 1045×12.5×12.519 55 11102
100-QS 7000seamed lid 2045×12.5×22.519 55 11202
100-QS14000seamed lid 4045×12.5×42.519 55 11402
100-QS17500seamed lid 5045×12.5×52.519 55 11502
100-QS35000seamed lid10045×12.5×102.519 55 11602
100-QX 3500seamed lid 1045×12.5×12.519 55 11104
110-OS 3500PTFE stopper 1045×12.5×12.519 55 12101
110-QS 350PTFE stopper 145×12.5×3.519 55 12012
110-QS 700PTFE stopper 245×12.5×4.519 55 12022
110-QS 1750PTFE stopper 545×12.5×7.519 55 12052
(2)110-QS 3500PTFE stopper 1045×12.5×12.519 55 12102
110-QS17500PTFE stopper 5045×12.5×52.519 55 12502
110-QX 3500PTFE stopper 1045×12.5×12.519 55 12104
(3)6030-OG 3500seamed lid 1045×12.5×12.519 55 10001
6030-OG 7000seamed lid 2045×12.5×22.519 55 10021
6030-OG14000seamed lid 4045×12.5×42.519 55 10031
6030-OG17500seamed lid 5045×12.5×52.519 55 10041
6030-UV 3500seamed lid 1045×12.5×12.519 55 10002
(4)117.100-QS1) 3500screw cap 1045×12.5×12.510 55 11172



1) For anaerobic applications, with ISO thread GL 14 and screw cap with silicone rubber seal


Semi-micro absorption cells

Inside width 4 mm

Type/materialVol.
µl		CoverOptical path length
mm		Outer dimensions H × W × D
mm		Base thickn.
mm		Order No.
6040-OG1400without lid1045×12.5×12.53.219 55 10009
(5)6040-UV1400without lid1045×12.5×12.53.219 55 10010
104-OS1400seamed lid1045×12.5×12.53.219 55 13101
104-OS7000seamed lid5045×12.5×52.53.219 55 13501
104-QS1400seamed lid1045×12.5×12.53.219 55 13102
104-QS7000seamed lid5045×12.5×52.53.219 55 13502
(6)104B-QS2)1400seamed lid1045×12.5×12.53.219 55 13602
108-QS1000seamed lid1045×12.5×12.5910 55 13702
(7)114-QS1400PTFE stopper1045×12.5×12.53.219 55 14122
114B-QS2)1400PTFE stopper1045×12.5×12.53.219 55 14132
117.104-QS1)1400screw cap1045×12.5×12.51.2510 55 14142



1) For anaerobic applications, with ISO thread GL 14 and screw cap with silicone rubber seal
2) Black side walls and base


Micro absorption cells

Optical path length 10 mm, inside width 2 mm

Type/materialVol.
µl		CoverOuter dimensions H × W × D
mm		Base thickness
mm		Order No.
104.002-OS700seamed lid45×12.5×12.53.219 55 14161
(8)104.002-QS700seamed lid45×12.5×12.53.219 55 14162
104.002B-QS700seamed lid45×12.5×12.53.219 55 14172
(9)105-QS300seamed lid25×12.5×12.51.510 55 14182
108.002-QS500seamed lid45×12.5×12.5910 55 14192
108.002B-QS500seamed lid45×12.5×12.5910 55 14193
115-QS400PTFE stopper40×12.5×12.51.2519 55 14192
115B-QS2)400PTFE stopper40×12.5×12.51.2510 55 14195



2) Black side walls and base


Ultra-micro absorption cells

with PE stopper



Material:quartz glass SUPRASIL®
Optical path length:10 mm
Outer dimensions (H×W×D):45 × 12.5 × 12.5 mm


Type/materialVol.
µl		Center height
mm		Aperture H × W
mm		Order No.
105.200-QS160158 × 210 55 12001
105.200-QS160 8.58 × 210 55 12002
(AT)105.201-QS100155 × 210 55 12011
105.201-QS100 8.55 × 219 55 10521
105.202-QS 50152.5 × 210 55 12021
105.202-QS 50 8.52.5 × 210 55 12022



Semi-micro cells for flow-trough measurements

with in/outlet tubes for absorbtion measurements



Window material:quartz glass SUPRASIL®
Aperture (H×W):11 × 4 mm


Type/materialVol.
µl		Optical path length
mm		Center height
mm		Outer dimensions H × W × D
mm		Order No.
176.000-QS 450101545×12.5×12.519 55 30102
(AK)176.000-QS2250501545×12.5×52.519 55 30502
176.000-QS2250508,538.5×12.5×52.519 55 30501



Compact cells for flow-through measurements

with 2 screw connectors M 6 × 1 and FEP tubes (outside Ø 1.9 mm, inside Ø 1.1 mm, 500 mm long)



Window material:quartz glass SUPRASIL®
Outside dim. (H×W×D):35 × 12.5 × 12.5 mm


Type/materialVol.
µl		Optical path length
mm		Center height
mm		Aperture H × W
mm		Order No.
170.700-QS3) 6.2 0.1all dim.17.5×3.519 55 22202
170.700-QS3) 12.4 0.2all dim.17.5×3.519 55 22212
170.700-QS3) 31 0.5all dim.17.5×3.519 55 22222
(AL)170.700-QS 62 1all dim.17.5×3.519 55 22252
170.700-QS124 2all dim.17.5×3.519 55 22322
176.700-QS195 51511×3.510 55 15051
176.700-QS195 5 8.511×3.510 55 15052
(AM)176.700-QS390101511×3.519 55 15102
176.700-QS39010 8.511×3.519 55 15832



3) with bypass


Macro fluorescence cells

with PTFE lid or stopper, triangular cell



Volume:3500 µl
No. of windows:4
Optical path length:10 × 10 mm
Inside width:10 mm
Base thickness:1.25 mm


TypeWindow materialOuter dimensions H × W × D
mm		Order No.
(AN)101-OSSpecial optical glass45×12.5×12.519 55 11511
101-QSQuartz SUPRASIL®45×12.5×12.519 55 11512
111-OSSpecial optical glass46×12.5×12.519 55 12511
111-QSQuartz SUPRASIL®46×12.5×12.519 55 12512
(AO)117.100F-QS1)Quartz SUPRASIL®56×12.5×12.510 55 13512



1) For anaerobic applications, with ISO thread GL 14 and screw cap with silicone rubber seal


Semi-micro fluorescence cells



Window material:Quartz SUPRASIL®
No. of windows:4
Optical path length:10 × 4 mm
Inside width:4 mm


TypeVol.
µl		CoverOuter dimensions H × W × D
mm		Base thickness
mm		Order No.
104F-QS1400seamed lid45×12.5×12.51.2519 55 14112
(AP)114F-QS1400PTFE stopper46×12.5×12.51.2510 55 15112
(AQ)119.004F-QS1500PTFE stopper49,5×12.5×12.5510 55 11194
117.104F-QS1)1400screw cap56×12.5×12.51.2510 55 11174



1) For anaerobic applications, with ISO thread GL 14 and screw cap with silicone rubber seal


Micro fluorescence cells



Window material:Quartz SUPRASIL®
Optical path length:10 × 2 mm
Inside width:2 mm


TypeVol.
µl		CoverOuter dimensions H × W × D
mm		Base thickness
mm		Order No.
104.002F-QS700seamed lid45×12.5×12.51.2519 55 14182
(AR)108.002F-QS500seamed lid45×12.5×12.5910 55 14183
115F-QS400PTFE stopper40×12.5×12.51.2510 55 14184



Ultra-mikro fluorescence cells

with PTFE stopper



Window material:Quarzglas SUPRASIL®
No. of windows:3
Outside dim. (H×B×T):45 × 12.5 × 12.5 mm


TypeVol.
µl		Optical path length
mm		Inner dimensions
mm		Center height
mm		Order No.
105.250-QS10010 × 25 × 21510 55 12501
(AS)105.250-QS10010 × 25 × 2 8.510 55 12502
105.251-QS 453 × 35 × 31510 55 12511
105.251-QS 453 × 35 × 3 8.510 55 12512



Cells for light-scattering measurements

with PTFE stoppers, window material quartz SUPRASIL®

TypeVol.
µl		Outside dim. H × Ø
mm		Inner dimensions
mm		Order No.
540.110-QS 280075 × 1075 × 810 55 15400
540.111-QS4) 280075 × 1075 × 810 55 15401
(BT)540.135-QS1400075 × 2075 × 1810 55 15405



4) polished outer cylinder


Demountable cells
TypeVol.
µl		Optical path length
mm		Order No.
(BK)106-QS 2.60.01 ± 0.00310 55 11061
106-QS260.1 ± 0.00510 55 11062
106-QS520.2 ± 0.00510 55 11063
(BL)013.000, holder for cell type 106-QS10 55 11069
